MetalWorks Tin - 56009 - 56009B3L9

Line: MetalWorks Tin

Product Type
Product Family
Chat Live
MetalWorks Tin

DOWNLOADS

TOOLS

LEED CREDITS

LEED Credit Area Contribution
MR Credit 2.1, 2.2 Construction Waste Management
MR Credit 4.1, 4.2 Recycled Content
MR Credit 5.1, 5.2 Regional Materials
EQ Credit 4.1 to 4.6 Low-Emitting Materials
EQ Credit 4.4 Low-Emitting Materials
EQ Credit 4 Option 6 Low-Emitting Materials (CHPS)
Item # 56009B3L9      Relative Installed Cost Relative Installed Cost Relative Installed Cost Relative Installed Cost



VISUAL SELECTION

Dimensions:
24 x 24 x IN

Grid Face:
9/16 IN

Edge Profile:
Square Lay-In

Visual Design:
56009

Perforation Design:
B3 - Extra MicroPerforated

Shape:
Panel

Available Colors:
Tin Lacquered Steel

Tin Lacquered Steel

Tin White

Tin White
Tin Copper

Tin Copper
Tin Bare Steel

Tin Bare Steel
Tin Chrome

Tin Chrome


PERFORMANCE SELECTION

Acoustics NRC:   0.25
Acoustics CAC:   N/A
Acoustics AC:   N/A
Fire Resist/ Flame spread:   Class A
Light Reflectance:   0.77
Humidity Resistance:   Standard
Clean Room Classification: None
Anti-microbial:   Standard
Durability Impact Resistance Impact resistance
Maintainability Washability

Scrubability

Soil Resistance
Washable


Scrubable


Soil resistance

Accessibility

Accessibility: Yes

PHYSICAL DATA

Material:
Metal, Embossed
Texture:
Smooth
Pattern:
No Pattern
Surface Finish:
Varies depending on color
Weight:
0.80 (lbs/sqft)
Sq Ft (Sq Ft/Carton):
4.0
ASTM Classification:
Type: XX, Form: N/A, Pattern: C J Z
Insulation Value:
R Factor-BTU: N/A , R Factor-Watts: N/A

INSTALLATION SELECTION

Installation Method: Grid (Suspended)
Recommended Grid Systems

Suprafine XL 9/16" Exposed Tee
