MetalWorks Torsion Spring - 7209M16

Line: MetalWorks Torsion Spring

Product Type
Product Family
Chat Live
MetalWorks Torsion Spring

DOWNLOADS

TOOLS

LEED CREDITS

LEED Credit Area Contribution
MR Credit 4.1, 4.2 Recycled Content
MR Credit 5.1, 5.2 Regional Materials
EQ Credit 4.1 to 4.6 Low-Emitting Materials
LEED for Schools
EQ Prerequisite 3 Minimum Acoustical Performance
EQ Credit 4 Option 6 Low-Emitting Materials (CHPS)
EQ Credit 9 Enhanced Acoustical Performance for Schools
Item # 7209M16      Relative Installed Cost Relative Installed Cost Relative Installed Cost Relative Installed Cost



VISUAL SELECTION

Dimensions: 24 x 24 x 1.25 IN
Grid Face: 15/16 IN
Edge Profile: Square
Perforation Design: M16
Shape: Panel
Available Colors:
Laminates Wild Cherry

Laminates Wild Cherry
Gun Metal

Gun Metal
Laminates Rock Maple

Laminates Rock Maple
Laminates Light Cherry

Laminates Light Cherry
Brushalume

Brushalume
Whitelume

Whitelume

Silverlume

Silverlume
Satin Anodized

Satin Anodized
Lacquer Mill

Lacquer Mill


PERFORMANCE SELECTION

Acoustics NRC: High Acoustical 0.70
Acoustics CAC:   N/A
Acoustics AC:   N/A
Fire Resist/ Flame spread:   Class A
Light Reflectance:   0.77
Humidity Resistance:   Standard
Clean Room Classification: None
Anti-microbial:   Standard
Formaldehyde Level: No Added
Durability Impact Resistance Impact resistance
Maintainability Washability

Scrubability

Soil Resistance
Washable


Scrubable


Soil resistance

Accessibility

Accessibility: Yes

PHYSICAL DATA

Material: Metal, Formed
Texture: Smooth
Pattern: Perforations
Surface Finish: Polyester paint, acrylic latex paint on acoustically transparent membrane, or vinyl-faced membrane
Weight: 0.69 (lbs/sqft)
Sq Ft (Sq Ft/Carton): 4.0
ASTM Classification: Type: XX, Form: N/A , Pattern: C
Insulation Value: R Factor-BTU: N/A , R Factor-Watts: N/A

INSTALLATION SELECTION

Installation Method: Grid (Suspended)
Recommended Grid Systems

Prelude XL 15/16" Exposed Tee
